DENKA

Product Information

Non-Halogen Binding Tape

Product Information

Outline

【S-25】

This is a polyethylene-based fastening tape. It is particularly well suited to fastening polyethylene film, and is highly recyclable.

【S-26/S-26TS】

This is a new type of binding and protective tape that uses no PVC materials. It is suited to binding applications, because it leaves very little adhesive residue on the material it is adhered to.

Characteristics

【S-25】
  • The use of an acrylic adhesive makes it adhere more strongly to polyethylene products.
  • It is easier to work with because it can be torn by hand easily.
【S-26/S-26TS】
  • This product is designed to prevent adhesive residue, so it has less impact on the materials it is adhered to.
  • It is easier to work with because it can be torn by hand easily.

・This product does not intentionally use toxic substances designated by the EU’s RoHS Directive. (S-25/S-26/S-26TS)

Uses

【S-25】
  • Binding of manuals for electrical products, office equipment, and other binding uses
【S-26/S-26TS】
  • Binding and protection of such construction materials as stainless-steel plates, aluminum sashes, and plastic sashes
  • Surface protection
Cautions for Use

After the tape is removed, adhesive residue may be left on the material it is adhered to, or the surface may be damaged, depending on the type of material, the length of adhesion, or the environment. Be sure to check before use.

Related Information

Specifications

Product number Width(mm) Length(m) Packing(rolls) Paper pipe diameter(inch)
NKT‐S‐25 10 30 200 1.3
13 250
19 200
Standard Colors Transparent
NKT‐S‐26 13 50 132
15 120
19 96
Standard Colors White
NKT‐S-26TS 15 50 120 3
19 96
50 36
Standard Colors White

Physical Properties (These properties are typical values. They are not guarantees.)

Item Measured values
S-25/S-26/S-26TS
Thickness mm 0.1
Adhesive strength N/cm 1.5
Back adhesive strength mm/60minute 0.8

Standard Colors

Contact Us

Electronics & Innovative Products

High Functional Adhesive Materials Dept.
TEL
+81-3-5290-5538
FAX
+81-3-5290-5777
  • It is the customer’s responsibility to always test products before use and confirm their fitness for purpose and safety.
  • Any product contained on this Website or any product using a product contained on this Website should be disposed of in accordance with laws and regulations.
  • Before use, please confirm the detailed method of use, precautions, and other information by using the technical documentation and Material Safety Data Sheet. These materials are available from the relevant Division. Please request them.
  • The information contained in this website is subject to change without notice as new knowledge becomes available.
