DENKA

Product Information

VINI-TAPE® (Vinyl Tape)

Product Information

Outline

  • VINI-TAPE® is a Lead-Free & None DOP environmental electrical tape for all wire and cable joints rated up to 600 V.
  • DENKA has been manufacturing VINI-TAPE® over 60 years and providing more than 60 countries such as South East, Middle East Asia, Latin America and African countries.
  • # 261D is electrical tape approved by IEC 60454-3-1-1.

*Note: VINI-TAPE® is a registered trademark of Denka (Denka Company Limited.).

vinitape

web leaflet

Characteristics

  • High Quality
    VINI-TAPE® is a good quality electrical tape inquality and has excellent resistance to corrosion. Due to a elastic tape backing and high quality design of the adhesive, the tape shall be applied to not only conform and produce a uniform covering in long term, but also prevent from flagging. The high quality of VINI-TAPE® provides to relieve your amount of repair work.
  • Excellent Workability
    VINI-TAPE® has easy cut quality for a special process in the side of the tape. Therefore, VINI-TAPE® helps you to improve the work efficiency further more.
  • Cold Resistance
    With the fine resistance to cold temperature, the properties of adhesive maintain its quality.
  • Excellent Storability
    VINI-TAPE® tends to be stored in the warehouse which is even relatively in high temperature. VINI-TAPE® is not deformed with high temperature and holds its shape. Good stock rotation is recommended.
  • Wide Range of Colors
    Bright and clear nine standard colors identify diversify cables easily and accomplish good appearance after binding.
  • Environmental friendly pressure sensitive adhesive
    We do not intentionally use any of the substances in EU regulations of RoHS and REACH on VINI-TAPE® , unless the substance is in an application that is exempt under these regulations.

Uses

  • Terminal processing of power-cables, wiring and insulation of electrical joints.
  • Protection, binding, and identification of cables and pipes.
  • Protection, repairs, and binding for homes, construction, tying works,
    and other uses.
  • Bundling and repairing automotive wire harnesses.

Related Information

SDS VINI-TAPE

#101 VINI-TAPE

Specifications

Thickness (mm) Width (mm) Length Packing (rolls)
0.2 19 10 Yards 500
10 Meters 500

Standard Colors

Physical Properties

Peel adhesion Tensile strength Elongation Volume resistivity Withstand voltage
N/10mm N/10mm % MΩ・cm 5000V×1minute
Adhesion test panel Adhesion backing
1.68 2.19 36.4 191 6.99x108 Good

* Reference values only.
* If you need other colors or specifications, please contact us.

#102 VINI-TAPE

Specifications

Thickness (mm) Width (mm) Length Packing (rolls)
0.15 19 10 Yards 500

Standard Colors

Physical Properties

Peel adhesion Tensile strength Elongation Volume resistivity Withstand voltage
N/10mm N/10mm % MΩ・cm 5000V×1minute
Adhesion test panel Adhesion backing
1.55 2.05 27.3 188 2.90x108 Good

* Reference values only.
* If you need other colors or specifications, please contact us.

#103 VINI-TAPE

Specifications

Thickness (mm) Width (mm) Length Packing (rolls)
0.13 19 10 Yards 500

Standard Colors

Physical Properties

Peel adhesion Tensile strength Elongation Volume resistivity Withstand voltage
N/10mm N/10mm % MΩ・cm 5000V×1minute
Adhesion test panel Adhesion backing
1.24 1.89 23.3 180 2.05x108 Good

* Reference values only.
* If you need other colors or specifications, please contact us.
